Waters Autospec Premier - Electrical Power Outlets

To Next Page

To Previous Page

1-14 Instrument description

Magnet power transformer

Electrical power outlets

Electrical power outlet connections

The following electrical power outlets appear on the rear of the instrument:

• Two 240 V a.c. 10 A maximum

• Power outlets for the following vacuum pumps:

240V 10AMP MAX.

SOURCE ANALYSER INLET 1 INLET 2
