Controls and connections on the rear of the instrument 1-11
Controls and connections on the rear of the instrument
Rear view of the instrument
Warning: A trip hazard exists at the rear of the instrument because of
the large number of cable and pipe connections; take great care when
working in this area.
Warning: A pinch hazard exists at the rear of the instrument. Do not
put your fingers between the air mount frame and top of the
instrument’s cubicles.
Cooling water
connections
Electrical power outlets
Vacuum connections
Gas inlet panel
Soft-vent control panel
EPC power switch
Magnet power connection
