D-40 The MassLynx Tune window

The AGHIS tab parameters

The AGHIS (All-Glass Heated Inlet System) tab is available only when Inlet >

AGHIS is selected.

AGHIS page

AGHIS page parameters

Parameter

Minimum

Value

Maximum

Value

Default

Value

AGHIS Re-entrant Enable 0 450 0

AGHIS Band Enable 0 450 0
