Waters Autospec Premier - The Lenses 2 Tab Parameters (for Analyzer Resolution

The Tune window tuning controls D-37
The Lenses 2 tab parameters (for analyzer resolution)
See “AutoSpec functionality” on page G-2.
Lenses 2 tab
Lenses 2 tab parameters
Parameter
Minimum
Value
Maximum
Value
Default
Value
Y Focus 0 5000 4000
Rotate 2 -150.0 150.0 0.0
Curve 2 -150.0 150.0 0.0
Curve 3 -150.0 150.0 0.0
Rotate 3 -150.0 150.0 0.0
Rotate 4 -150.0 150.0 0.0
