Waters Autospec Premier - The Lenses 1 Tab Parameters (for Analyzer Intensity

D-36 The MassLynx Tune window
The Lenses 1 tab parameters (for analyzer intensity)
See “AutoSpec functionality” on page G-2.
Lenses 1 tab
Lenses 1 tab parameters
Parameter
Minimum
Value
Maximum
Value
Default
Value
Y Deflect 1 -150.0 150.0 0.0
Z Deflect 1 -150.0 150.0 0.0
Z Deflect 2 -150.0 150.0 0.0
Z Focus 2 0 5000 2500
Z Focus 3 0 5000 2500
Z Deflect 3 -150.0 150.0 0.0
