7-58 Routine maintenance

Disassembling the inner source contact support assembly

Inner source contact support assembly components

Key to inner source contact support assembly components

Item Description

A Inner source contact support plate

B Filament contact

C Repeller contact

D 2-mm ceramic spacer

E 3.5-mm ceramic spacer

F Trap contact

Hole for ceramic support
