The Tune window tuning controls D-35
The FI Source tab parameters
FI Source tab
FI Source tab parameters
Parameter
Minimum
Value
Maximum
Value
Default
Value
Extraction Voltage (kV) -10.0 0.0 0.0
Extraction Limit (kV) -10.0 0.0 -5.0
Focus 1 0 2500 600
Beam Centre -150.0 150.0 0.0
Focus 2 2500 5000 4300
Emitter Scan Current 0.0 100.0 0.0
Emitter Scan Current Limit 0.0 100.0 100.0
Heater Current (mA) 0.00 2.50 0.00
