Waters Autospec Premier

To Next Page

To Previous Page

7-52 Routine maintenance

2. Remove the 12-mm ceramic spacer from each ceramic rod.

3. Remove the Focus 1 plate from the ceramic rods.

12-mm ceramic spacer

Focus 1 plate
