Setting up scanning functions 3-9
To set up a Magnet Scan function
1. In the MS method editor, click .
Alternative: Click Functions > Magnet Scan.
2. In the Magnet Scan function editor, enter the required parameters.
3. Click OK.
See “The Magnet Constant Utility dialog box” on page D-14.
Inter-Scan Delay (s) The time between one scan’s end and the next scan’s
start, in seconds. No data are collected during this
time; the time is used to allow the magnet to settle,
and to transfer collected data from the EPC to the
MassLynx PC.
Tip: This value is typically set to 10% of the scan
time (s per decade). However, if the calibration at
the high mass end is poor, the value set may be too
small.
Total Cycle Time (s) Displays the total time per scan cycle, in seconds.
Magnet Scan function editor parameters (Continued)
Parameter Description
