Xerox PHASER 6010 Service Manual

Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 2-45
Theory of Operation
Data Flow
The print data (electric signal) from the printer controller flows as shown in the
following illustration before it is turned into a print.
s6000-111
Host (Electric Signal)
Electronic Sub-System Control Board (Electrical Signal)
Machine Control Unit (Electric Signal)
LPH (LEDs)
Electrostatic Latent on Drum (Invisible Image)
Toner Image on Drum
Toner Image on Belt
Toner Image on Paper
Print Image on Paper
