Xerox PHASER 6010 Service Manual

5-34 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Image Quality
Unfused Image
The image is not completely fused to the paper. The image easily rubs off.
Initial Actions
• Check the media path.
• Check the Fuser connection (P/J171).
5 Inspect the Registration Roller and
the Registration Pinch Roller for wear
or damage.
Is either part worn or damaged?
Replace the
Registration
Roller
(page 8-61) or
the
Registration
Pinch Roller
(page 8-57),
then go to
step 6.
Go to step 7.
6 Does the image print correctly? Complete. Go to step 7.
7 Replace the Feed Roller and the Left
and Right Feed Roller Cams
(page 8-45).
Does the image print correctly?
Complete. Go to step 8.
8 Replace the Separator Pad
(page 8-49).
Does the image print correctly?
Complete. Go to step 9.
9 Replace the MCU Board
(page 8-121).
Does the image print correctly?
Complete. Contact your
designated
field support for
assistance.
Troubleshooting Procedure Table (Continued)
Step Actions and Questions Yes No

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
