Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 7-7
Cleaning and Maintenance
Cleaning the Color Toner Density Sensors
The Color Toner Density Sensors (ADC Sensors) measure the optical density of
toner deposited on the marking unit during the calibration cycles of the printing
process. One sensor is located at each side of the marking unit to insure that the
density of the toner is consistent across the belt. To insure optimum print quality,
the printer checks the operation of the ADC Sensors at the beginning of each
calibration cycle. When the printer indicates an ADC Sensor error on the Control
Panel or in the Printer Setting Utility, clean the ADC Sensors.
Do not use warm water or cleaning solvents to remove toner from your skin or
clothing. Warm water sets the toner and makes it difficult to remove. If toner
gets on your skin or clothing, brush it off, blow it off, or wash it off with cold
water and mild soap.
Never touch a labeled area found on or near the heat roller in the Fuser. You
can get burned.
To clean the ADC Sensors:
1. Turn off the printer and unplug it from the power source.
2. Open the Rear Door.
3. Clean the ADC Sensors by wiping inside the access holes with a clean, dry
cotton swab.
4. Close the Rear Door.
Cleaning the Document Glass
To clean the document glass, gently wipe the glass with a clean, dry, lint-free cloth.
