9-4 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Parts List
Using the Parts List
Only parts showing part numbers are available for ordering by support. Parts
not showing part numbers are available on the parent assembly.
• Item: The callout number from the exploded part diagram.
• Name/Description: The name of the part to be ordered and the number of
parts supplied per order.
• Part Number: The material part number used to order that specific part.
• Parts identified throughout this manual are referenced PL#.#.#; For example,
PL3.1.10 means the part is item 10 of Parts List 3.1.
• A black triangle preceding a number followed by a parenthetical statement in
an illustrated parts list means the item is a parent assembly, made up of the
individual parts called out in parentheses.
•The notation “with X~Y” following a part name indicates an assembly that is
made up of components X through Y. For example, “1 (with 2~4)” means part
1 consists of part 2, part 3, and part 4.
• An asterisk (*) following a part name indicates the page contains a note about
this part.
•The notation “J1<>J2 and P2” is attached to a wire harness. It indicates that
connector Jack 1 is attached to one end of the wire harness and connector J2
is attached to the other end that is plugged into P2.
• Fastener location and type are indicated using designators listed in the
following table. Refer to “Fastener Types” on page 8-5 for a complete list of
fasteners used, and “Hardware Kit” on page 9-41 for fasteners available in the
Hardware Kit.
Parts Diagram Fastener Designators
Designator Fastener Type
EE-ring
KL K-clip
ST Screw, self-tapping
SM Screw, sheet metal
