Xerox PHASER 6010 - ASIC Failure

Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 3-107
Error Messages and Codes
ASIC Failure
ASIC Failure.
Applicable Error
• 124-333: ASIC Failure
Initial Actions
• Cycle printer power.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ LED Driver Board, PL7.1.5
■ LED/MCU Cable, PL7.1.6
■ MCU Board, PL7.2.2
■ “Map 3 - Phaser 6000/6010” on
page 10-9
■ “Phaser 6000/6010 Xerographics” on
page 10-14
■ “Phaser 6000/6010 Image Processor
Board” on page 10-18
■ “Map 3 - WorkCentre 6015 MFP” on
page 10-23
■ “WorkCentre 6015 MFP Xerographics”
on page 10-28
■ “WorkCentre 6015 MFP Image
Processor Board” on page 10-32
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check connectors P/J23 and P/J1 on
the MCU Board and LED Driver
Board.
Are the connections secure?
Go to step 3. Reconnect the
connectors
P/J23 and P/J1,
and then go to
step 2.
2 Does the error persist? Go to step 3. Complete.
3 Disconnect the MCU Board P/J23
and the LED Driver Board P/J1, and
check the LED/MCU Cable
continuity.
Is the cable damaged?
Replace the
LED/MCU
Cable
(page 8-111).
Go to step 4.
4 Replace the LED Driver Board
(page 8-107).
Does the error persist?
Replace the
MCU Board
(page 8-121).
Complete.
