8-24 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Service Parts Disassembly
WorkCentre 6015 MFP Rear Door
PL1.1.6
1. Open the Rear Door.
2. Release the right side boss of the Rear Door (located adjacent to the power
receptacle) from the hole in the printer.
WorkCentre 6015 MFP Rear Cover
PL1.1.10
1. Remove the Top Cover (page 8-22).
2. Remove the Rear Door (page 8-24).
s6015-067
