Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 3-47
Error Messages and Codes
Wireless Error
A wireless error is detected.
Applicable Errors
• 018-338: Wireless Error
Initial Actions
• Cycle printer power.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board, PL7.1.9B
■ Wireless Harness, PL1.1.31
■ Wireless Board Bracket, PL1.1.30
■ “Map 2 - WorkCentre 6015 MFP” on
page 10-22
■ “WorkCentre 6015 MFP Image
Processor Board” on page 10-32
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the connections between the
IP Board and the Wireless Board.
Are P/J6601 and P/J6501 properly
connected?
Go to step 2. Reconnect the
connections,
then go to
step 2.
2 Does the error persist? Go to step 3. Complete.
3 Disconnect P/J6601 on the IP Board,
and P/J6501 on the Wireless Board.
Is each cable of the Wireless
Harness continuous?
Go to step 4. Replace the
Wireless
Harness.
4 Replace the Wi-Fi Board.
Does the error persist when the
power is turned on?
Replace the IP
Board
(page 8-114).
Complete.
