Xerox PHASER 6010 Service Manual

10-28 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Wiring
WorkCentre 6015 MFP Xerographics
LED Driver
Board
PL7.1.5
(LPH Y/M/C/)
LPH Developer Belt
PL3.1.1
P/J xx*1
FFC LPH YMCK
SG
VCC 5V
RESET
SCL (SCK)
SDA (DI)
SG (DO)
Pull up 3.3V (CS)
VCC 5V
SG
VDATA 3 P
VDATA 3 N
VDATA 2 P
VDATA 2 N
VDATA 1 P
VDATA 1 N
VDATA 0 P
VDATA 0 N
VCC 5V
SG
VCLK P
VCLK N
SG
VCC 5V
HSYNC
MODE
READY
VCC 5V
SG
1.5V RETURN
1.5V RETURN
1.5V RETURN
1.5V RETURN
1.5V RETURN
1.5V RETURN
VCC 1.5V
VCC 1.5V
VCC 1.5V
VCC 1.5V
VCC 1.5V
VCC 1.5V
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
P/J xx*2
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
MCU Board
PL7.2.2
P/J 1
FFC Assembly Light Biz
PL7.1.6
+3.3V
+5V
+5V
SG
SG
MOB 1
MOB 2
SDAT
SCLK
RESET
INT
1
2
3
4
5
6
7
8
9
10
11
P/J23
11
10
9
8
7
6
5
4
3
2
1
Belt
CTD
(ADC)
TR0*3
(MOB)
P/J14
SG
Vmon
LED-K
VOUT
+5V
LED
VOUT
SG
+5V
5
4
3
2
1
6
7
8
9
P/J140
P/J141
1
2
3
4
5
1
2
3
4
s6015-055

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
