Xerox PHASER 6010 Service Manual

Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 10-27
Wiring
WorkCentre 6015 MFP Drive
MCU Board
PL7.2.2
Developer Drive
PL6.1.6
Main Drive Assembly
PL6.1.2
P/J10
SG
1
2
4
5
6
3
8
7
P/J16
P/J160
9
8
7
6
5
4
3
2
I/L +24VDC
SG
I/L +24VDC
START / STOP
SG
REF CLOCK
GAIN CHANGE
M
s6015-060
Interlock
+24VDC
1
2
Main Motor Harness Assembly
PL6.1.7
Registration Sensor Harness Assembly PL2.2.25
Registration Sensor Harness Assembly PL2.2.26
I/L +24VDC
K MODE SOL ON (L) +24VDC
Interlock
+24VDC
7
8
9
K MODE SENSED (L) +3.3VDC
SG
3
2
1
PULL UP +3.3VDC
P/J122P/J12
+3.3VDC
K Mode
Switching Solenoid
K Mode
Switching Sensor

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
