Xerox PHASER 6010 Service Manual

8-14 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Service Parts Disassembly
Transfer Roller
PL1.1.7~9
1. Open the Rear Door.
2. Unclip the Left Transfer Roller Bearing (white), then rotate it and pull it off of
the Transfer Roller.
3. Unclip the Right Transfer Roller Bearing (black), then rotate it and pull it off of
the Transfer Roller.
4. Remove the Transfer Roller from the printer.
Replacement Note
The Right Transfer Roller Bearing is installed over the spring.
s6000-032

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
