Xerox PHASER 6010 Service Manual

Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 3-99
Error Messages and Codes
X Toner Low Density
The printer detects low density of toner in the indicated Toner Cartridge.
Applicable Error
• 093-919: X Toner Low Density
• 093-920: X Toner Low Density
• 093-921: X Toner Low Density
• 093-922: X Toner Low Density
Initial Actions
• Cycle printer power.
• Replace the indicated Toner Cartridge.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ MCU Board, PL7.2.2 ■ “Map 3 - Phaser 6000/6010” on
page 10-9
■ “Phaser 6000/6010 LVPS” on
page 10-11
■ “Phaser 6000/6010 Drive” on
page 10-13
■ “Map 3 - WorkCentre 6015 MFP” on
page 10-23
■ “WorkCentre 6015 MFP LVPS” on
page 10-25
■ “WorkCentre 6015 MFP Drive” on
page 10-27
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Clean the ADC sensor (page 7-7).
Does the error persist?
Go to step 2. Complete.
2 Check that MCU Board P/J14 is
securely connected?
Is the connection secure?
Go to step 3. Reconnect
P/J14, then go
to step 3.
3 Does the error persist? Replace the
MCU Board
(page 8-121).
Contact your
designated
field support
for assistance.
