Xerox PHASER 6010 Service Manual

Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 10-25
Wiring
WorkCentre 6015 MFP LVPS
MCU Board
PL7.2.2
1
3
P/J204
I/L +24VDC
1
2
3
P/J205
LINE
NUT
FG
Main Fan PL7.1.2
FAN +24VDC
FAN ALARM
SG
P/J17
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
4
2
1
2
3
Interlock Switch
PL1.1.12
+5V-LPH
+5V-LPH
+5V-LPH
SG
SG
SG
Sleep
Fan High
Fan Enable
Fan Alarm
Geat1
Fuser Relay
IL Open
+24v On
+24V Ret
+24V Ret
+24V Ret
+24V MCU
+24V MCU
+24V MCU
Inlet Harness Assembly
PL7.2.9
P/J200
s6015-053
LVPS
PL7.2.1
3
1

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
