Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 8-123
Service Parts Disassembly
Reload the MCU Board NVM Data (Phaser 6000/6010)
1. Start the CE Diags Tool (page A-4).
2. Click the CE Diag tab, and then click NVM Settings - Load NVM from ESS.
3. Click the Start button.
The NVM data of the MCU Board is reloaded.
Reload the MCU Board NVM Data (WorkCentre 6015 MFP)
1. Power on the printer while pressing the Up and Down Arrow keys.
2. Press the Up or Down Arrow key to select Printer, and then press the OK key.
3. Press the Up or Down Arrow key to select IOT Diag, and then press the OK
key.
4. Press the Up or Down Arrow key to select NVM Settings, and then press the
OK key.
5. Press the Up or Down Arrow key to select LoadNVM from ESS, and then press
the OK key.
6. Press the OK key twice to execute LoadNVM from ESS.
HVPS
PL7.2.3
1. Remove the Main Paper Tray Cover (Phaser 6000/6010 page 8-7; WorkCentre
6015 MFP page 8-29).
2. Remove the Front Cover (Phaser 6000/6010 page 8-8; WorkCentre 6015 MFP
page 8-34).
3. Open the Rear Door.
4. Remove the Left Side Cover (Phaser 6000/6010 page 8-10; WorkCentre 6015
MFP page 8-29).
5. If present, remove the Wi-Fi Assembly (page 8-103).
6. Remove the Top Cover (Phaser 6000/6010 page 8-11; WorkCentre 6015 MFP
page 8-22).
7. Remove the Rear Cover (Phaser 6000/6010 page 8-15; WorkCentre 6015 MFP
page 8-24).

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
