Xerox PHASER 6010 Service Manual

3-28 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Error Messages and Codes
IP Memory Check Fail
A memory error occurred.
Applicable Error
• 016-315: IP RAM R/W Check Fail
• 016-317: IP ROM Check Fail
Initial Actions
• Cycle printer power.
• If the problem persists, use the following procedure.
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Reseat the Fuser and cycle system
power.
Does the error persist?
Go to step 2. Complete.
2 Check these connections
■ MCU Board P/J26 and P/J18.
■ LVPS P/J201.
Are the connectors secure?
Go to step 3. Secure the
connectors.
3 Check the Fuser harness.
1. Remove the Fuser.
2. Disconnect P/J26 and P/J18 from
the MCU Board and P/J201 from
the LVPS.
Is the harness damaged?
Repair the
harness.
Go to step 4.
4 Replace the Fuser (page 8-80).
Does the error persist?
Replace the
MCU Board
(page 8-121).
Complete.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board, PL7.1.9
■ MCU Board, PL7.2.2
■ LED Driver Board, PL7.1.5
■ “Map 2 - WorkCentre 6015 MFP” on
page 10-22
■ “Map 3 - WorkCentre 6015 MFP” on
page 10-23

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
