Xerox PHASER 6010 Service Manual

8-10 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Service Parts Disassembly
Phaser 6000/6010 Left Side Cover
PL1.1.21
1. Remove the Top Cover (page 8-11).
2. Open the Rear Door.
3. Release the 2 hooks on the lower side of the Left Side Cover.
4. Remove the Left Side Cover by releasing the hooks attached on the bottom of
the Left Side Cover.
Replacement Note
Engage the hooks on the rear side of the printer, and then engage the hooks
on the bottom of the Left Side Cover.
s6000-028

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
