Xerox PHASER 6010 - Phaser 6000;6010 HVPS

Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 10-15
Wiring
Phaser 6000/6010 HVPS
MCU Board
PL7.2.2
LPH Developer Belt
PL3.1.1
P/J21
1
2
3
4
5
6
7
8
9
10
11
12
13
HVPS
PL7.2.3
HVPS Harness
PL7.2.13
P/J210
BCR
BTR
BTR : Bias Transfer Roller
BCR : Bias Charge Roller
Developer
13
12
11
10
9
8
7
6
5
4
3
2
1
DEV DA
DEV AC
TR1+ DA
TR2- DA
TR2+ DA
TR1 I MON
TR2 I MON
CR DA
HV CLK
+3.3V
SG
SG
+24V
s6000-168
K
C
M
Y
