Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 4-23
Troubleshooting
Exit Sensor
1. Enter Service Diagnostics (page 4-11).
2. Run the Exit Sensor test: Engine Diag > Sensor Test > Exit Sensor.
3. Operate the actuator to check sensor function.
4. Confirm the number shown on the display increases every time the actuator is
operated.
5. Press the Cancel button to stop the test.
Paper
s6000-143
Exit Sensor Actuator
Paper

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
