Xerox PHASER 6010 Service Manual

Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 10-17
Wiring
Phaser 6000/6010 Fuser
MCU Board
PL7.2.2
P/J26
P/J18
2
1
SG
4
3
3
2
1
STS
1
3
N HEAT1
LINE
SG
STS 2
FUSER EXIT SENSED (L) +3.3VDC
SG
PULL UP +3.3VDC
Fuser
PL5.1.1
LVPS
PL8.2.1
s6000-170
Thermostat
Heater
P/J201
STS 1
STS 2
1
2
3
Exit
Sensor
+3.3VDC

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
