Xerox PHASER 6010 Service Manual

Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 5-49
Image Quality
Image Specifications
The following provide specifications for Skew, Parallelism, Linearity,
Perpendicularity, Magnification Error, Registration, and Guaranteed Print Areas.
Note
The printed image has 4.1 mm margins on all sides.
Characteristic Specification
Maximum Print Area 215.9 mm x 355.6 mm (8.5 inches x 14 inches)
Guaranteed Print Area 215.9 mm x 355.6 mm (8.5 inches x 14 inches)
Skew
Main Paper Tray (A4)
Main Paper Tray (LTR)
Bypass Tray (A4)
Bypass Tray (LTR)
180 mm ± 1.4 mm
200 mm ± 1.5 mm
180 mm ± 2.0 mm
200 mm ± 2.2 mm
Perpendicularity 140 mm ± 1.0 mm
Parallelism
A4 280 mm ± 1.3 mm
LTR 260 mm ± 1.3 mm
Linearity (Main Paper Tray)
Horizontal
A4
LTR
180 mm ± 0.5 mm
200 mm ± 0.5 mm
Vertical
A4
LTR
280 mm ± 0.6 mm
260 mm ± 0.6 mm
Slant
A4
LTR
254.5 mm ± 1.1 mm
282.8 mm ± 1.2 mm
Magnification Error
Horizontal
A4
LTR
180 mm ± 0.5 mm
200 mm ± 0.5 mm
Vertical
A4
LTR
280 mm ± 0.5 mm
260 mm ± 0.5 mm
Registration
Leading Edge ≤ ± 2.0 mm
Side Edge ≤ ± 2.5 mm

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
