Xerox PHASER 6010 Service Manual

5-48 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Image Quality
Drum Refresh Configuration Chart
This test print provides 20% density for combination
of yellow, magenta, cyan, and black on the whole
page. This test is used to identify problems with
balance of three color toners or another toner.
Compare the print with this example to determine the
problem.
• Checks Cyan, Magenta, or Yellow Toner Cartridge,
HVPS, Imaging Units, biasing contacts.
• Used to troubleshoot repeating defects, missing
colors, streaks, voids or banding.
s6015-110

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
