Xerox PHASER 6010 Service Manual

3-54 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Error Messages and Codes
USB Memory Full/USB Memory Write Error
A memory full error or USB memory write error occurred during a scan job.
Applicable Error
• 026-720: USB Memory Full
• 026-721: USB Memory Write Error
Initial Actions
• Check that the USB Cable connected to the printer and the PC is securely
connected.
• Cycle printer power.
• If the problem persists, use the following procedure.
5 Disconnect the MCU Board P/J12.
Is the voltage across ground and
J12-1 +3.3VDC?
Replace the
Registration
Sensor
(page 8-65).
Replace the
MCU Board
(page 8-121).
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board, PL7.1.9
■ MCU Board, PL7.2.2
■ “Phaser 6000/6010 Image Processor
Board” on page 10-18
■ “Map 2 - Phaser 6000/6010” on
page 10-8
■ “WorkCentre 6015 MFP Image
Processor Board” on page 10-32
■ “Map 2 - WorkCentre 6015 MFP” on
page 10-22
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the connectors on the IP
Board.
Are the connections secure?
Go to step 3. Securely
reconnect the
connectors,
then go to
step 2.
2 Does the error persist? Go to step 3. Complete.
3 Replace the IP Board (page 8-114).
Does the error persist?
Go to step 4. Complete.
4 Replace the MCU Board
(page 8-121).
Complete.
Troubleshooting Procedure Table
Step Actions and Questions Yes No

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
