Xerox PHASER 6010 Service Manual

2-68 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Theory of Operation
Main Drive Assembly
Paper Feed Drive Flow
The torque of the Main Drive Assembly is transmitted through the route shown in
the following illustration.
Motor Drive Assembly
Main Motor
Gear PF1
Gear PF2
[ Name of moving parts ]
Gear HR
Gear Idler HR
[ Heat Roller ]
Registration Clutch
Gear PH6 Gear PH4
MPT Feed Solenoid
Gear PH5
[ Exit Roller ]
Fuser
Gear Idler Exit
Gear Exit
[ Feed Roller ] [ Regi Roller ]
Registration AssemblyMPF & PSI
Gear Feed
Gear PH3 Gear F3
Gear F4
PH Drive Assembly
s6000-125

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
