Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 5-25
Image Quality
Auger Mark
Diagonal marks of non-uniform density in half tone areas appear on the image.
Initial Actions
• Ensure there is no debris on the transfer path.
Troubleshooting Reference Table
Applicable Parts Example Print
■ Transfer Roller, PL6.1.7
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Replace the Image Processor Board.
Does the image print correctly?
Complete. Contact your
designated
field support for
assistance.
s6000-203

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
