8-2 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Service Parts Disassembly
Overview
This section contains the removal procedures for field-replaceable parts listed in
the Parts List. In most cases, the replacement procedure is simply the reverse of
the removal procedure. In some instances, additional steps are necessary and are
provided for replacement of the parts. For specific assemblies and parts, refer to
Chapter 9.
Standard Orientation of the Printer
When needed, the orientation of the printer is called out in the procedure as an aid
for locating the printer parts. The following illustrations identify the Front, Rear,
Left, and Right sides of the printer.
Phaser 6000/6010 Printers
s6000-001
Rear
Right
Front
Left
