Xerox PHASER 6010 Service Manual

Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 7-9
Cleaning and Maintenance
Moving the Printer
The Phaser 6000/6010, with consumables installed weighs 11.3 kg (24.9 lb.), and
the WorkCentre 6015 MFP weighs 15.2 kg (33.51 lb.).
Caution
When moving the printer over long distances, remove the Toner Cartridges to
prevent toner from spilling.
Before moving the printer, do the following:
1. Turn the printer Off and disconnect all cables.
2. Allow the printer to cool about 40 minutes.
3. Remove media from the output tray and return the Tray Extension to its non-
extended position.
4. Remove the Bypass Tray, then push in the center paper guide until it stops.
5. Push in the side paper guides until they stop.
6. Place the Bypass Tray inside the printer, on the Main Tray.
7. Fold up the Main Tray Extension to cover the paper feed.
8. Lift and carry the printer as shown in the illustration.
s6000-160
11.3 kg
24.9 lb.
15.2 kg
33.51 lb.
s6015-112

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
