Xerox PHASER 6010 Service Manual

4-68 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Troubleshooting
DC Power Troubleshooting
Initial Actions
• Cycle printer power.
• If the problem persists, follow the procedure below.
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 When the printer is turned on, can
you hear the motor?
Go to step 2. Go to step 5.
2 Is the Control Panel working? Go to step 4. Go to step 3.
3 Reseat both ends of the Control
Panel cable.
Does the error persist?
Go to step 4. Complete.
4 Reseat the connectors on the Image
Processor Board.
Does the error persist?
Complete. Replace the
Processor
Board
(page 8-114)
and the
Control Panel
(page 8-101
for Phaser
6000/6010,
page 8-104 for
WorkCentre
6015 MFP).
5 Reseat the connectors on the MCU
Board.
Does the error persist?
Replace the
LVPS
(page 8-119).
Complete.

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
