3-72 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Error Messages and Codes
Fan Motor Failure
Fan motor failure.
Applicable Error
• 042-358: Fan motor failure
Initial Actions
• Cycle printer power.
• If the problem persists, use the following procedure.
5 Check the Main Drive harness
continuity.
Disconnect P/J16 from the MCU
Board and P/J160 from the Main
Drive Assembly to check continuity.
Is the harness damaged?
Repair the
harness.
Go to step 6.
6 Check the power to the Main Drive
Assembly.
Disconnect connector P/J16 on the
MCU Board.
Are the voltages across ground at
P/J16-2 and P/J16-4 approximately
+24 VDC when the Interlock Switch
is closed?
Replace the
Main Drive
Assembly
(page 8-82).
Replace the
MCU Board
(page 8-121).
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ LVPS, PL 7.2.1
■ Fan, PL 7.1.2
■ MCU Board, PL7.2.2
■ “Map 2 - Phaser 6000/6010” on
page 10-8
■ “Phaser 6000/6010 Fuser” on
page 10-17
■ “Map 3 - WorkCentre 6015 MFP” on
page 10-23
■ “WorkCentre 6015 MFP Fuser” on
page 10-31
Troubleshooting Procedure Table
Step Actions and Questions Yes No

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
