Xerox PHASER 6010 Service Manual

4-30 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Troubleshooting
Feed Solenoid
The Feed Roller rotates when the Main Motor (FULL) and the Feed Solenoid tests
are executed simultaneously.
1. Enter Service Diagnostics (page 4-11).
2. Remove the Bypass Tray.
3. Run the Main Motor Full and Feed Solenoid tests: go to Engine Diag > Motor
Tes t > Main Motor Full and press OK, then scroll down to Feed Solenoid and
press OK.
4. Check that the Feed Roller rotates.
5. Press the Cancel button to stop the Feed Solenoid test.
6. Use the Down Arrow to scroll to the motor test, and press Cancel to stop the
motor test.
7. Replace the Bypass Tray.
s6000-150
Feed Roller

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
