3-86 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Error Messages and Codes
Exit On Jam
The paper does not reach the Exit Sensor within the specified time.
Applicable Error
• 077-106: Exit On Jam
Initial Actions
• Check the media path for obstructions or debris.
• Cycle printer power.
• If the problem persists, use the following procedure.
15 Disconnect P/J16 on the MCU
Board.
Are the voltages across ground at
P/J16-2 and P/J16-4 approximately
+24 VDC when the Interlock Switch
is pushed?
Replace the
Main Drive
Assembly
(page 8-82),
then go to
step 16.
Replace the
MCU Board
(page 8-121),
then go to
step 16.
16 Does the error persist when printing? Go to step 17. Complete.
17 Enter diagnostic mode and run the
Regi Clutch test.
You can also use the CE Diag Tool to
run this test (see page A-16).
Does the Registration Clutch
function correctly?
Replace the
MCU Board
(page 8-121).
Replace the
Registration
Clutch
(page 8-66).
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Registration Sensor, PL2.3.5
■ Registration Clutch, PL2.3.7
■ Harness Assembly RKN SNS,
PL2.2.25/26
■ Main Drive Assembly, PL6.1.2
■ Harness Assembly Main MOT,
PL6.1.7
■ MCU Board, PL7.2.2
■ “Map 3 - Phaser 6000/6010” on
page 10-9
■ “Phaser 6000/6010 Feeder” on
page 10-12
■ “Phaser 6000/6010 Drive” on
page 10-13
■ “Map 3 - WorkCentre 6015 MFP” on
page 10-23
■ “WorkCentre 6015 MFP Feeder” on
page 10-26
■ “WorkCentre 6015 MFP Drive” on
page 10-27
Troubleshooting Procedure Table
Step Actions and Questions Yes No
To Next Page
