Xerox PHASER 6010 Service Manual

2-36 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Theory of Operation
• Cleaning Blade
Removes the toner remaining on the drum after the toner image is transferred
to the print medium.
• Magnet Roller
The magnet roller contacts the drum to form the toner image on the drum
surface.
•Auger
The auger agitates the toner particles.
• Trimmer
The trimmer uniformly levels the toner/carrier particles deposited on the
surface of the magnet roller.
Transfer Belt
Major Functions
• 1st BTR Roller (Y/M/C/K)
Attracts the toner image on the drum to the transfer belt by positively
charging the transfer belt from the backside.
•Transfer Belt
Receives the four color-separated toner images from each drum in registration
with one another.
Belt
Cleaning Blade
Back Up Roller
1st BTR (K)
1st BTR (C)
1st BTR (M)
1st BTR (Y)
s6000-104

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
