Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 2-61
Theory of Operation
Fax Standards (ITU-T Recommendations)
International FAX standards (ITU-T recommendations) include G1 to G4. G1 to G3
use analog telephone networks. G4 uses a digital telephone network (ISDN). G3 is
the standard currently in greatest use. FAXes conforming to Super G3, a recently
added standard, are equipped with a fast 33.6kps modem and reduce
transmission times to about half those of G3 FAXes.
Standard &
Year Issued
Minimum
Transmission
Time for
Single-Page
A4 Document
Maximum
Resolution
Maximum
Transmission
Speed Features
Group 1 (G1)
1968
Approx. 6 min. 100 x 100 dpi (Analog) Analog
transmission.
No band
compression.
Group 2 (G2)
1976
Approx. 3 min. 100 x 100 dpi (Analog) Analog
transmission.
Band
compression
technology
adopted.
Group 3 (G3)
1980
Approx. 1 min. 200 x 200 dpi 14.4 kbps
(Super G3:
33.6 kbps)
Connection to
analog line
using Fax
modem.
Image data in
digital format.
Data
compression.
Most common
standard in
use.
Group 4 (G4)
1988
Approx. 3 sec. 400 x 400 dpi 64 kbps
(using ISDN)
Digital
transmission.
Supported by
various digital
transmission
services.
Halftone
supported.

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
