Xerox PHASER 6010 Service Manual

Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 2-71
Theory of Operation
Full Color Mode Development Drive Components
s6000-128
Front
: Indicates The Engagement Of Gears
[ Name Of Moving Parts ]
Motor Drive
Main Motor
Gear D1
Gear D2
Magnet Gear (Y)
Magnet Gear (M)
Magnet Gear (C)
Magnet Gear (K)
Magnet Gear
[ Magnet Roll ]
Magnet
Idler Gear
Admix Auger Gear
Auger Gear
[ Auger Supply ]
[ Auger Admix ]
Xerographic Developer (Y)
Xerographic Developer (M)
Xerographic
Developer (C)
Xerographic
Developer (K)
Gear D6 (K)
Gear
D6 (C)
MU Drive
Developer Drive
Gear Idler D2
Gear Idler D1
Gear Idler D2
Idler Gear D2
Gear
Idler D1
Gear Idler D2
Gear D5
Gear D3C
Gear D3C
Gear
D6 (M)
Gear D6 (Y)
Gear D5
Gear D4 In
Gear DK1
Switching Solenoid
Gear DK2
Flange D4
Gear D4 In
Gear D4 Out

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
