Xerox PHASER 6010 Service Manual

3-74 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Error Messages and Codes
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the P/J10 connector on the
MCU Board.
Is P/J10 connected correctly?
Go to step 2. Reseat the
connector. Go
to step 2.
2 Does the error persist when the
power is turned on?
Go to step 3. Complete.
3 Test the Feed Solenoid.
Enter diagnostic mode and select
Engine Diag > Motor Test > K Mode
Solenoid (see “Using Phaser 6010N
and WorkCentre 6015 MFP Service
Diagnostics” on page 4-10).
You can also use the CE Diag Tool to
perform this test (page A-16).
Does the Feed Solenoid function
normally?
Go to step 4. Replace the
Feed Solenoid
(page 8-98).
4 Check the connections between the
MCU Board P/J12 and the Feed
Sensor P/J122.
Are the connections secure?
Go to step 5. Reseat the
connector. Go
to step 5.
5 Does the error persist when the
power is turned on?
Go to step 6. Complete.
6 Disconnect the MCU Board P/J21
and the Registration Sensor P/J120.
Check the Harness Assembly RKN
SNS for continuity.
Is the harness damaged?
Repair the
harness.
Go to step 7.
7 Disconnect P/J12 on the MCU
Board. Is the voltage across ground
to P/J12-7 approximately +3.3 VDC?
Replace the
Developer Drive
Assembly.
Replace the
MCU Board
(page 8-121).

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
