Xerox PHASER 6010 Service Manual

Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 3-103
Error Messages and Codes
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check that the Toner Cartridges
installed in the printer are Xerox
cartridges.
Are the Toner Cartridges installed in
the printer Xerox Toner Cartridges?
Go to step 2. Complete.
2 Disconnect P/J13 on the MCU Board
and unlace the harness. Inspect the
harness for damage.
Is the harness damaged?
Repair the
harness, then
go to step 3.
Go to step 3.
3 Does the error persist? Replace the
MCU Board
(page 8-121),
then go to
step 4.
Complete.
4 Disconnect P/J13 on the PWBA
MCU.
Is the voltage across ground to
P/J13-3 on the MCU Board
approximately +3.3 VDC?
Repair the
Harness
Assembly
DCKR.
Go to step 5.
5 Replace the Toner Cartridge (C, M, Y,
or K).
Does the error persist?
Replace the
MCU Board
(page 8-121).
Complete.

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
