Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 1-5
General Information
WorkCentre 6015 MFP
Item Description Item Description
1Bypass Tray 9Document Glass
2 Feeder Guides 10 LED Cleaning Rod
3Platen Cover 11Power Switch
4 Output Tray 12 Front Cover
5 Output Tray Extension 13 Main Paper Tray
6 Control Panel 14 Main Tray Extension
7 ADF Input Tray 15 USB Connector
8 Toner Door Handle
12
64 5 73 8
9
1114 1213 1015
