Xerox PHASER 6010 Service Manual

1-16 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
General Information
WorkCentre 6015B Color
MFP
USB 2.0 ■ Connector Type: One Type A, One Type B
■ Protocol: Hi-speed USB 2.0 compatible
WorkCentre 6015N Color
MFP
USB 2.0 ■ Connector Type: One Type A, One Type B
■ Protocol: Hi-speed USB 2.0 compatible
Ethernet
■ Connector Type: One RJ-45 connector
■ 10 BASE-T/100 BASE-TX compatible
WorkCentre 6015NI Color
MFP
USB 2.0 ■ Connector Type: One Type A, One Type B
■ Protocol: Hi-speed USB 2.0 compatible
Ethernet
■ Connector Type: One RJ-45 connector
■ 10 BASE-T/100 BASE-TX compatible
Wireless
■ Compliant Standard: IEEE802.11b/g
■ Security Protocol: WEP (64/128bits), WPA-PSK
(TKIP, AES), WPA-2PSK (AES)
■ Certifications: Wi-Fi, WPA2.0
■ Wi-Fi Protected Setup (WPS): Push Button
Configuration (PBC), Personal Identification
Number (PIN)
Operating System
Phaser 6000/6010
Mac Mac OS X 10.5 or later
Windows Windows 7 (32/64 bit), Windows XP (32/64 bit),
Vista (32/64 bit), 2003 Server (32/64 bit),
2008 Server (32/64 bit)
Linux Supported
WorkCentre 6015 MFPs
Mac Mac OS 10.4.11/10.5.8 or later, and 10.6.X
(Power PC, Intel X86 Processors)
Windows Windows 7 (32/64 bit), Windows XP (32/64 bit),
Vista (32/64 bit), 2003 Server (32/64 bit),
2008 Server (32/64 bit), 2008R2 (64 bit)
Linux Supported
Memory Specifications Memory
Phaser 6000B ■ Main Memory: 64 MB
■ Flash ROM: 2 MB
Phaser 6010N
■ Main Memory: 128 MB
■ Flash ROM: 8 MB
Printer Specifications (Continued)
Characteristic Specifications

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
