Xerox PHASER 6010 Service Manual

9-8 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Parts List
Parts List 1.1 WorkCentre 6015 MFP Covers
Item Parts name Part Number
1A Cover Assembly Top (with 2-4,23) (Top Cover)
2 Cover Extension (Output Tray Extension)
4 Cover Top (Top Cover) 848E 67410
6 Cover Assy Rear (Rear Door) 848K 49871
7 Left Transfer Roller Bearing 013E 38091
8 Right Transfer Roller Bearing 013E 38101
9 Roll Assembly BTR (Transfer Roller) 059K 66830
10A Cover Inner Rear (Inner Rear Cover) (WorkCentre
6015B MFP)
676K 03180
10B Cover Inner Rear (Inner Rear Cover) (WorkCentre
6015N/NI MFP)
604K 66400
11 —
12 Switch I/L (Rear Cover Interlock Switch) 676K 12440
13 Holder IL Rear
14 —
15 Cover Window TNR (Toner Door) 848E 67463
16 Hinge Cover
17 Cover (Main Paper Tray Cover) 676K 03230
18 Lower Front Cover
19 —
20 —
21 Cover Side L (Left Side Cover) 848E 67451
22 —
23 Spring IIT
24 Arm IIT
25 Holder Arm L
26 Holder Arm R
27 Output Tray Extension
28 —
29 —
30 Bracket Assembly Wi-Fi (Wireless Board)
31 Harness Assembly Wi-Fi LT (Wireless Harness)
32 Package Assembly Wi-Fi (with 30, 31) 101K 61442
33 Holder Assembly Arm L (Left Scanner Arm) 019K 11690
34 Holder Assembly Arm R (Right Scanner Arm) 019K 11700

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
