Xerox PHASER 6010 Service Manual

9-28 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Parts List
Parts List 6.1 Drive
Item Parts name Part Number
1 Drive Assembly MU
2 Drive Assembly MOT (Main Drive Assembly) 007K 17072
3 Gear F3 (F3 Drive Gear) 807E 32380
4 Gear PH3 (PH3 Drive Gear) 807E 32390
5 Drive Assembly PH (Feed Drive Assembly) 007K 17091
6 Drive Assy Deve (Developer Drive Assembly) 007K 17087
7 Harness Assembly Main MOT (J16-J160)
8 Gear Feed
9Spring Feed
10 Solenoid Feed (Feed Solenoid) 121E 22671
99 Drive Assembly Mot (With 2, 3, 4, and 5) (Main Drive
Assembly Kit)
604K 64630

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
