Xerox PHASER 6010 Service Manual

9-38 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Parts List
Parts List 8.1 WorkCentre 6015N/NI MFP Scanner
Item Parts name Part Number
1 Scanner Assembly 4In1 604K 70711
2 ADF Assembly (with 3-7) (ADF)
3 Cover Assembly Top ADF (ADF Cover) 604K65550
4 ADF Separator Pad (with 5) 604K65560
5 Spring Separator
6 Tray Assembly Input ADF (ADF Input Tray) 604K65530
7ADF Hinge Assembly TBD
8IIT Assembly 3IN VB
9—
10B Console Assembly 4IN (Control Panel) (See 13 and
14 below)
11 SSB Cover
12 Rail IIT FB
13 Control Panel Board TBD
14 LCD TBD
96 Label FAX 897E82971

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
