Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 10-3
Wiring
Denotes a connection between parts with
harness or wires, attached with signal
name/contents.
Denotes function, and logic value of the signal
to operate the function (Low: L, High: H). The
given voltage is for signal in high status. The
arrow indicates the direction of signal.
Denotes function, and logic value of the signal
when the function operated (Low: L, High: H).
The given voltage is for signal in high status.
The arrow indicates the direction of signal.
Denotes a connection between wires.
Denotes a Clutch or Solenoid.
Denotes a Motor.
Denotes a Photo Sensor.
Denotes an LED.
Denotes a Safety Interlock Switch.
Symbol Description
DEVE_A
Connection Wire
CLUTCH ON(L)+24V
Function Logic 1
EXIT SENSED(L)+3.3VDC
Function Logic 2
Connection of Wires
Solenoid/Clutch
M
Motor
Optic Sensor
LED
Safety Interlock Switch

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
