10-6 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Wiring
112 2 H-123 Connects LED Driver Board and LED Driver Board
120 2 E-125 Connects Registration Sensor and RKN SNS Harness
(6010N Only)
120 2 E-125 Connects Registration Sensor and RKN SNS Harness
(6000B Only)
121 2 F-125 Connects No Paper Sensor and RKN SNS Harness
(6010N Only)
122 2 H-125 Connects Deve Drive Assembly (K Mode Switching
Sensor) and RKN SNS Harness (6010N Only)
122 2 H-125 Connects Deve Drive Assembly (K Mode Switching
Sensor) and RKN SNS Harness (6000B Only)
130 1 I-107 Connects Toner CRUM (K) and DCKR Harness
131 1 I-107 Connects Toner CRUM (C) and DCKR Harness
132 1 H-107 Connects Toner CRUM (M) and DCKR Harness
133 1 H-107 Connects Toner CRUM (Y) and DCKR Harness
140 2 C-123 Connects ADC Sensor and ADC1 TRO Harness
(Marking Unit) (6010N Only)
140 2 C-123 Connects ADC Sensor and ADC Harness (Marking
Unit) (6000B Only)
141 2 E-124 Connects Mark On Belt Sensor and ADC1 TRO
Harness (Marking Unit) (6010N Only)
160 2 H-124 Connects Main Drive Assembly and MAIN MOT
Harness
200 1 H-110 Connects Toner Motor (CK) and Dispense MOT
Harness
200 3 B-139 Connects LVPS and AC Inlet Harness
201 1 G-110 Connects Toner Motor and Dispense MOT Harness
201 3 C-139 Connects LVPS and Fuser
202 3 E-138 Connects LVPS and LVES Harness
204 3 F-139 Connects LVPS and Interlock Switch
205 3 F-139 Connects LVPS and Fan
206 3 E-138 Connects LVPS and FSR Test Harness
208 1 G-109 Not Connected (Used in production process only)
210 3 F-139 Connects HVPS and HVPS Harness
220 1 B-106 Connects Control Panel and Console Harness
220 2 G-125 Not Connected
401 2 H-122 Connects LED Driver Board and LVES Harness
402 2 H-122 Connects LED Driver Board and Image Processor
Harness
404 2 G-124 Not Connected
406 2 G-124 Not Connected
407 2 H-123 Connects LED Driver Board and Console Harness
Phaser 6000/6010 Plug and Jack Designators (Continued)
P/J Map Coordinates Remarks
